Fanco Infinity-iD Key Features
It has ABS plastic blades that are lightweight and UV-resistant, ideal for outdoor installations. The controls offer a convenient way to adjust your fan’s settings from a distance. With its user-friendly interface the remote and smart functionality, you can easily control the fan’s speed, light control and set a timer for automatic shut-off (1H, 4H or 8H).
| Installation Location | Indoor, Outdoor Undercover & Coastal |
|---|---|
| Blade Material | ABS Plastic |
| Overall Diameter | 122cm (48″) |
| Blade Pitch | 14 Degrees |
| Motor Type | DC motor |
| Operation | Remote Control | Smart Control |
| Summer / Winter use? | Reversible from remote & smart app |
| Ceiling to Blade Drop | 270mm (291mm to base of light) |
| Angled Ceilings? | Suitable for angled ceilings up to 10 degrees |
| Light | Included |
Fanco Infinity-iD Performance Data
| Speed | RPM | Wattage | Airflow |
|---|---|---|---|
| 1 | 60 | 1 | 2773 m3/hr |
| 2 | 90 | 2 | 4863 m3/hr |
| 3 | 130 | 5 | 7129 m3/hr |
| 4 | 170 | 10.5 | 8843 m3/hr |
| 5 | 215 | 21.5 | 10870 m3/hr |
| 6 | 255 | 39 | 12573 m3/hr |
Tailor the airflow to your preference, from a gentle breeze to a powerful cooling effect with the 6-speed settings. The summer/winter mode reverses the blade’s direction, promoting air circulation in winter and providing a cooling effect in summer.
About the Fanco Infinity-iD Light
| Light Type | LED |
|---|---|
| Light Wattage | 20W |
| Lumens | 1309lm, 1495lm or 1608lm |
| Light Temperature | 3000K, 4000K or 5000K |
| Dimmable | Yes |
This light kit features CCT Technology. This means that you are able to select your preferred light temperature.
Want to know more about how the SMART app works? Visit the Fanco website or click here Fanco SMART Manual.
Please note: Enclosed Outdoors: Products installed at least 1.5m from the perimeter of the roof/eaves of the enclosure (to protect the product from direct or indirect rainwater or sunlight). This model utilises a DC motor. However, it has an internal converter and is, therefore, compatible with normal AC electrical systems. It cannot be connected directly to a DC power source. The fan and components must be installed by qualified persons.
