Fanco Infinity-iD Key Features
Engineered with premium virgin ABS blades for lasting strength and smooth performance. The included remote lets you adjust fan speeds and set 1H, 4H, or 8H timers for effortless comfort.
| Installation Location | Indoor, Outdoor Undercover & Coastal |
|---|---|
| Blade Material | ABS Plastic |
| Overall Diameter | 122cm (48″) |
| Blade Pitch | 14 Degrees |
| Motor Type | DC motor |
| Operation | Remote Control |
| Summer / Winter use? | Reversible from remote |
| Ceiling to Blade Drop | 270mm |
| Angled Ceilings? | Suitable for angled ceilings up to 10 degrees |
| Light | Not Included |
Fanco Infinity-iD Performance Data
| Speed | RPM | Wattage | Airflow |
|---|---|---|---|
| 1 | 60 | 1 | 2,733 m3/hr |
| 2 | 90 | 2 | 4,863 m3/hr |
| 3 | 130 | 5 | 7,129 m3/hr |
| 4 | 170 | 10.5 | 8,843 m3/hr |
| 5 | 215 | 21.5 | 10,870 m3/hr |
| 6 | 255 | 39 | 12,573 m3/hr |
Choose from 6-speed settings for anything from a gentle breeze to strong cooling. The Summer/Winter mode reverses blade direction for better airflow in winter and cooling in summer.
Please note: Enclosed Outdoors: Products installed at least 1.5m from the perimeter of the roof/eaves of the enclosure (to protect the product from direct or indirect rainwater or sunlight). This model utilises a DC motor. However, it has an internal converter and is, therefore, compatible with normal AC electrical systems. It cannot be connected directly to a DC power source. The fan and components must be installed by qualified persons.
