530m3/hr

SM Mixflow Inline Fan 150 with plug

Name: SM Mixflow Inline Fan 150 with plug
SKU: EXHGHF150
Availability: OutOfStock

$149.00

The Fanco SM Mixflow 150 (EXHGHF150) is a fantastic value inline fan that is used typically for exhaust, air transfer or other applications that require mechanical ventilation. The SM Mixflow comes by default on the high speed setting which has an impressive extraction speed of 530 m3/hr. To switch to the lower speed, an electrician is required to rewire the fan to the lower speed terminal (this model doesn’t have a speed controller). This will then produce an extraction speed of 410 m3/hr with the added benefit of operating at a reduced noise level.

This fan has not been formally tested for official noise levels.

—–

CUSTOMER NOTICE – This product is currently out of stock & not available for purchase. If you need some advice on alternatives please contact us.

—–

SKU: EXHGHF150 Categories: Fanco Exhaust Fans, Inline Fans, Mixed Flow Inline Fans, SM Mixflow Inline Fans

Secure
Checkout

4.9 Google
Shop Rating

Fast + Free
Shipping*

Please Note: A maximum temperature of transferred air 60°. This inline fan is designed for indoor application with the ambient temperature ranging from +1°C up to 40° C & relative humidity up to 80%.

Manufacturers Part Number	EXHGHF150
Colour	White
Capacity (m3/hr)	0530 m3/hr
Capacity (l/s)	147.22 l/s
Current	0.22A
Noise Level	TBC
IP Rating	IPX4
Duct Size	150mm
Material	Plastic
Installation	This fan comes with a lead and plug for connection to a powerpoint.
Manufacturer	Fanco
Warranty	1 year replacement warranty
General Exhaust Fan Advice	It is recommended to achieve a minimum of 15 air changes per hour in a bathroom to remove excess moisture., To work this out, calculate the volume of air in the room ( length x width x height, all in meters) and multiply this by the number of air changes to get the required air volume of the fan.
Barcode Number	0754523090818
