Fanco Horizon Key Features
Built with high-quality ABS blades for consistent performance and a refined aesthetic. A user-friendly remote enables simple speed control and flexible 1 to 9-hour timer functions.
| Installation Location | Indoor, Outdoor Undercover & Coastal |
|---|---|
| Blade Material | ABS Plastic |
| Overall Diameter | 132cm (52″) |
| Blade Pitch | 17 Degrees |
| Motor Type | DC motor |
| Operation | Remote Control | Smart Control |
| Summer / Winter use? | Reversible from remote & smart app |
| Ceiling to Blade Drop | 300mm (320mm to base of motor) |
| Angled Ceilings? | Suitable for angled ceilings up to 15 degrees |
| Light | Not Included |
Fanco Horizon Performance Data
| Speed | RPM | Wattage | Airflow |
|---|---|---|---|
| 1 | 60 | 5.3 | 3240 m3/hr |
| 2 | 88 | 6.5 | 5760 m3/hr |
| 3 | 116 | 8.8 | 7551 m3/hr |
| 4 | 145 | 13.1 | 9829 m3/hr |
| 5 | 174 | 18.5 | 12277 m3/hr |
| 6 | 200 | 25.3 | 13862 m3/hr |
Tailor the airflow to your preference, from a gentle breeze to a powerful cooling effect with the 6-speed settings. The summer/winter mode reverses the blade’s direction, promoting air circulation in winter and providing a cooling effect in summer.
Want to know more about how the SMART app works? Visit the Fanco website or click here Fanco SMART Manual.
Please note: Enclosed Outdoors: Products installed at least 1.5m from the perimeter of the roof/eaves of the enclosure (to protect the product from direct or indirect rainwater or sunlight). This model utilises a DC motor. However, it has an internal converter and is, therefore, compatible with normal AC electrical systems. It cannot be connected directly to a DC power source. The fan and components must be installed by qualified persons.
