Fanco Infinity-iD Key Features
It has ABS plastic blades that are lightweight, UV-resistant, and corrosion-resistant. The controls offer a convenient way to adjust your fan’s settings from a distance. With its user-friendly interface, you can easily control the fan’s speed, light control and set a timer for automatic shut-off (1H—9H).
Installation Location | Indoor, Outdoor Undercover & Coastal |
---|---|
Blade Material | Plastic |
Overall Diameter | 137cm (54″) |
Blade Pitch | 13 Degrees |
Motor Type | DC motor |
Operation | Remote Control & Smart Control |
Summer / Winter use? | Reversible from remote & SMART control |
Ceiling to Blade Drop | 270mm (330mm to base of light) |
Angled Ceilings? | Suitable for angled ceilings up to 7 degrees |
Light | Included |
Fanco Infinity-iD Performance Data
Speed | RPM | Wattage | Airflow |
---|---|---|---|
1 | 60 | 3.4 | 3,420 m3/hr |
2 | 88 | 4.6 | 4,644 m3/hr |
3 | 116 | 6.8 | 6,049 m3/hr |
4 | 145 | 10 | 7,021 m3/hr |
5 | 174 | 15.2 | 8,641 m3/hr |
6 | 200 | 22.5 | 10,801 m3/hr |
Tailor the airflow to your preference, from a gentle breeze to a powerful cooling effect with the 6-speed settings. The summer/winter mode reverses the blade’s direction, promoting air circulation in winter and providing a cooling effect in summer.
About the Fanco Infinity-iD Light
Light Type | LED |
---|---|
Light Wattage | 22w |
Lumens | 1300lm, 1600lm or 1500lm |
Light Temperature | 3000K, 4200K, or 3000K |
Dimmable | Yes |
This light kit features CCT Technology. This means that you are able to select your preferred light temperature.
Want to know more about how the SMART app works? Visit the Fanco website or click here Fanco SMART Manual.
Please note: Enclosed Outdoors: Products installed at least 1.5m from the perimeter of the roof/eaves of the enclosure (to protect the product from direct or indirect rainwater or sunlight). This model utilises a DC motor. However, it has an internal converter and is, therefore, compatible with normal AC electrical systems. It cannot be connected directly to a DC power source. The fan and components must be installed by qualified persons.
