Hunter Pacific Pinnacle v2 DC Ceiling Fan with LED Light – Brushed Aluminium with Silver Blades 52″
Original price was: $539.00.$489.00Current price is: $489.00.
The Pinnacle 52″ ceiling fan offers a sophisticated, minimalist solution for contemporary interiors and covered outdoor spaces. Its clean lines and brushed aluminium finish complement modern and industrial designs. Four aerodynamic ABS blades and an efficient DC motor deliver impressive airflow (15,101 m³/h max) while consuming minimal power (2.7W low speed). Integrated 18W dimmable CCT LED light included for your lighting needs. A 9-speed wall/remote control, reversible functionality, and compatibility with HPI Pixie Module (see accessories) provide versatile control and smart home integration. It is suitable for indoor, outdoor, and coastal installations and is ideal for living areas, patios, and pergolas. A 7-year warranty ensures long-term performance.
—–
CUSTOMER NOTICE – This product is currently out of stock & not available for purchase. If you need some advice on alternatives please contact us.
—–
Need an Electrician to Install This Fan?
Click here to learn how you can book installation post purchase
Hunter Pacific Pinnacle v2 DC Main Features
The Pinnacle 2 typically comes with ABS polymer blades designed for optimal airflow and a DC motor delivering strong and consistent airflow with energy efficiency. An accessory 38-degree canopy kit can be purchased separately for installation on raked ceilings up to 38 degrees. (See accessories)
| Installation Location | Indoor, Outdoor Undercover & Coastal |
|---|---|
| Blade Material | Plastic |
| Overall Diameter | 132cm (52″) |
| Blade Pitch | 12 Degrees |
| Motor Type | DC motor |
| Operation | Remote Control|Wall Control |
| Summer / Winter use? | Reversible from remote & wall control |
| Ceiling to Blade Drop | 255mm (315mm to base of motor) |
| Angled Ceilings? | Suitable for FLAT ceilings only |
| Light | Included |
Hunter Pacific Pinnacle v2 Performance Data
| Speed | RPM | Wattage | Airflow |
|---|---|---|---|
| 1 | 79 | 2.7 | 4953 m3/hr |
| 2 | 93 | 3.8 | 5943 m3/hr |
| 3 | 150 | 9.6 | 9734 m3/hr |
| 4 | 159 | 12.5 | 11001 m3/hr |
| 5 | 174 | 15.4 | 11987 m3/hr |
| 6 | 189 | 17.6 | 12254 m3/hr |
| 7 | 199 | 21.1 | 13954 m3/hr |
| 8 | 209 | 22.5 | 14038 m3/hr |
| 9 | 215 | 25.3 | 15101 m3/hr |
The fan features several speed settings, enabling users to tailor the airflow to their personal preferences and the room’s specific needs.
About the Hunter Pacific Pinnacle v2 Light
| Light Type | LED |
|---|---|
| Light Wattage | 18 |
| Lumens | 1842lm, 2370lm or 2123lm |
| Light Temperature | 3000K, 4000K or 6000K |
| Dimmable | Yes |
This light kit features CCT Technology. This means that you are able to select your preferred light temperature.
| Manufacturer | Hunter Pacific |
|---|---|
| Manufacturers Part Number | PL2207 |
| Overall Diameter | 52" (1320mm) |
| Motor Type | DC |
| Motor Colour | Brushed Aluminium |
| Blade Colour | Brushed Aluminium |
| Number of Blades | 4 |
| Control | Remote Control, Wall Control |
| Light | Integrated LED Light |
| Light Wattage | 18W |
| Dimmable | Yes |
| Suitable for Angled Ceilings | Suitable for FLAT Ceilings only |
| Warranty | Hunter Pacific: This fan comes complete with a 3 year in-home manufacturer's warranty on the fan followed by a 4 year extended parts only warranty on the motor only. |
| Installation Location | Indoor, Outdoor – Fully Undercover, Coastal |
Dimensions
Blade Span: 52″ (132cm)
Ceiling to Blade Drop: 255mm
Ceiling to Base of Light: 315mm
