Fanco Eco Style DC Main Features
With a diameter of 132 cm (52 inches) and a 15-degree blade pitch, this fan efficiently cools small to medium-sized rooms.
Installation Location | Indoor, Outdoor Undercover |
---|---|
Blade Material | Plastic |
Overall Diameter | 132cm (52″) |
Blade Pitch | 15 Degrees |
Motor Type | DC motor |
Operation | Remote Control |
Summer / Winter use? | Reversible from remote |
Ceiling to Blade Drop | 295mm |
Angled Ceilings? | Suitable for angled ceilings up to 15 degrees |
Light | Not Included |
Fanco Eco Style Performance Data
Speed | RPM | Wattage | Airflow |
---|---|---|---|
1 | 75 | 3.8 | 5010 m3/hr |
2 | 125 | 9.5 | 7860 m3/hr |
3 | 140 | 14 | 8250 m3/hr |
4 | 160 | 18.5 | 8950 m3/hr |
5 | 170 | 24 | 9378 m3/hr |
6 | 190 | 33 | 9641 m3/hr |
The fan boasts a wide range of speeds, achieving 9,641 m³/hr on the highest setting.
Please note: This fan includes two extension rods (125mm long and 250mm long). The ceiling to blade drop of 295mm is achieved by using the smaller (125mm) rod. Colour variations may be attributed to differences in monitors/screens, lighting sources, digital photography, and individual perceptions of colours.
Aswin –
No remote control and the wall control was not intuitive.
